Cheetah 125 ATV

SPECIFICATIONS

ENGINE
Engine Type 107 cc,Air cooled, 4-stroke, single-cylinder
Start Type Electric Start
Transmission Chain Drive
Engine Gear F-N-R
Shift Gear Foot
Max Torque 6.5N.m/5000-5500r/min
Ignition CDI
Fuel Tank Capacity 1 Gallon

CHASSIS
Front Hand Brake Drum
Rear Foot Brake Hydraulic Disc
Tire Front 19 x 7 – 8
Tire Rear 18 x 9.5 – 8
Front Suspension 12.4 Inches
Rear Suspension 11 Inches
Speed Limiter Yes
Engine kill switch Yes
Battery 12V/4Ah
Wheelbase 41.4 Inches

DIMENSION
G.W 235 LBS
N.W 210 LBS
Max Loading 132 LBS
Carton Size 51 x 30 24 inches
Seat Height 24.81 inches
Ground Clearance 3.55 inches
